Intelligent cable crane solution for sustainable sediment removal

LCS Sediment Management System

Efficient. Environmentally friendly. Scalable.
The innovative alternative to conventional belt conveyor systems for reservoirs and mining applications.

Your challenge | Our solution

Reservoirs and tailing dams require regular clearing. Conventional methods often reach their limits.

The LCS sediment management system offers a logistically optimized solution for continuous sediment removal – even under demanding topographical and ecological conditions.

Thanks to the LCS cable crane solution, rigid ground-based transport infrastructure can be eliminated for onward transport, minimizing interventions in the landscape and the environment.

The illustrated design, featuring two independent cable crane lines combined with a central transfer point, enables a high degree of operational flexibility. This creates a continuous, safe, and approval-friendly sediment logistics process.

Sediment transport process using a cable crane system

Step 1: Sediment extraction & containerization

Suction or floating dredgers transport sediment from the bottom of the reservoir to the surface and fill containers on a floating barge.

Step 2: First transport stage

The full container can be loaded from the barge at any point along the defined route of Line 1 and transported to the transfer point.

Step 3: Transfer & buffering

At the strategically positioned transfer point, the handover between the two lines takes place. Material can also be buffered here to ensure continuous operation.

Step 4: Second transport stage

Line 2 transports the containers to the final disposal site or to the downstream area – efficiently and with precise control.

Step 5: Discharge & return cycle

The containers are emptied at the defined location and returned to the barge in a closed-loop cycle – a sophisticated system for maximum efficiency.

Key facts about cable crane systems for material transport

length

up to

3,000 m

Payload

up to

50 t

Lifting Speed

up to

1.5 m/s

Travel Speed

up to

7 m/s

Lifting Height

up to

200 m

Steep Terrain

up to

70°
